OPT Electrician Tools

TOPT-LY-03C

For insulated terminals and connectors.

Ratchet type.

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-AN-03C

For insulated terminals and connectors.

Ratchet type.

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-FN-03C

For insulated terminals and connectors.

Ratchet type.

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-SN-02C

For insulated terminals and connectors.

Ratchet type.

Crimping range: 0.25 – 2.5mm2

Weight: 0.35kg

Length: 190mm2

TOPT-LY-03C-5D

Dies (TOPT-LY-03C) For Insulated Terminal & Connector

Dies (TOPT-LY-03B) For Non-insulated Receptacle & Tab Terminal

Dies (TOPT-LY-04WF) Dies (TOPT-LY-16WF) For Wire Ferrules & End Sleeves

Dies (TOPT-LY-10) For Non-insulated Terminal

TOPT-LY-03B

For insulated receptable & tab terminals.

Ratchet type. Tab width = 6.3mm

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-SN-02B

For open barrel terminal & non-insulated receptable tab terminal.

Tab width = 6.3mm/4.8mm

Crimping range: 0.5 – 2.5mm2

Weight: 0.35kg

Length: 190mm

TOPT-SN-28B

For open barrel terminal & non-insulated receptable tab terminal.

Tab width = 2.8mm

Crimping range: 0.25 – 1mm2

Weight: 0.35kg

Length: 190mm

TOPT-KH-6

For cable lug / non-insulated terminal.

Ratchet type. PVC Handle. Smart-open knob.

Crimping range: 0.75 – 6mm2

Weight: 0.23kg

Length: 195mm

TOPT-KH-8

For cable lug / non-insulated terminal.

Ratchet type. PVC Handle. Smart-open knob.

Crimping range: 1.5 – 10mm2

Weight: 0.6kg

Length: 250mm

TOPT-KH-16

For cable lug / non-insulated terminal.

Ratchet type. PVC Handle. Smart-open knob.

Crimping range: 1.5 – 16mm2

Weight: 0.6kg

Length: 280mm

TOPT-KH-22

For cable lug / non-insulated terminal.

Ratchet type. PVC Handle. Smart-open knob.

Crimping range: 6 – 25mm2

Weight: 0.92kg

Length: 365mm

TOPT-KH-38

For cable lug / non-insulated terminal.

Ratchet type. PVC Handle. Smart-open knob.

Crimping range: 6 – 35mm2

Weight: 0.92kg

Length: 365mm

TOPT-KH-120

For copper cable lug and link.

Non ratchet adjusting screw type.

Crimping range: 10 – 95mm2

Weight: 2.8kg

Length: 558mm

TOPT-KH-150

For copper cable lug and link.

Non ratchet adjusting screw type.

Crimping range: 10 – 120mm2

Weight: 3.5kg

Length: 595mm

TOPT-LY-06WF

For wire ferrule and end sleeve.

Ratchet type.

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-LY-16WF

For wire ferrule and end sleeve.

Ratchet type.

Crimping range: 6 – 16mm2

Weight: 0.6kg

Length: 230mm

TOPT-LY-35WF

For wire ferrule and end sleeve.

Ratchet type.

Crimping range: 10 – 35mm2

Weight: 0.6kg

Length: 240mm

TOPT-LY-50WF

For wire ferrule and end sleeve.

Ratchet type.

Crimping range: 25 – 50mm2

Weight: 0.6kg

Length: 240mm

TOPT-ANB-06WF

For wire ferrule and end sleeve.

Ratchet type. Premium handle.

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-FN-06WF

For wire ferrule and end sleeve.

Ratchet type. Premium handle.

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

Length: 230mm

TOPT-FN-35WF

For wire ferrule and end sleeve.

Ratchet type. Premium handle.

Crimping range: 10 – 35mm2

Weight: 0.6kg

Length: 240mm

TOPT-KH-35WF

For wire ferrule and end sleeve.

Ratchet type. PVC Handle. Smart open knob.

Crimping range: 10 – 35mm2

Weight: 0.64kg

Length: 280mm

TOPT-KH-95WF

For wire ferrule and end sleeve.

Ratchet type. PVC Handle. Smart open knob.

Crimping range: 50 – 95mm2

Weight: 0.76kg

Length: 330mm

TOPT-LK-22A

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 22mm2

Weight: 0.2kg

Length: 160mm

TOPT-LK-38A

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 38mm2

Weight: 0.3kg

Length: 210mm

TOPT-LK-60A

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 60mm2

Weight: 0.5kg

Length: 235mm

TOPT-LK-125A

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 125mm2

Weight: 0.7kg

Length: 300mm

TOPT-LK-250

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 250mm2

Weight: 1.2kg

Length: 530mm

TOPT-LK-325

For copper and aluminium cable.

Cutting range: 325mm2

Weight: 2.1kg

Length: 600mm

TOPT-LK-500

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 500mm2

Weight: 3.0kg

Length: 770mm

TOPT-LK-550

For copper and aluminium cable.

Cutting blades are made of heavy duty forged steel.

Cutting range: 550mm2

Weight: 3.2kg

Length: 800mm

TOPT-LK-300B

For copper and aluminium cable.

Cutting range: 300mm2

Weight: 0.6kg

Length: 240mm

TOPT-LK-450A

For copper and aluminium cable.

Cutting range: 400mm2

Weight: 0.96kg

Length: 240mm

TOPT-LK-760L

For copper and aluminium cable.

Cutting range: 500mm2

Weight: 0.9kg

Length: 430mm

TOPT-LK-1050L

For copper and aluminium cable.

Cutting range: 1000mm2

Weight: 3.8kg

Length: 680mm

TOPT-KN-20B

Features: SK5 Blade

Length: 180mm

TOPT-KN-070103

Features: 1000V Insulated

Length: 200mm

TOPT-KN-070104

Features: 1000V Insulated

Length: 430mm

TOPT-LY-600N

Width of cable tie : Max 7.9mm, thickness 0.3mm

Length: 180mm

TOPT-LY-600F

Width of cable tie : Max 4.5mm-12mm

Length: 200mm

TOPT-LY-700B

Stripping range : 6-1/2”

(Dia. of cutting blade : 1, 1.6, 2, 2.6, 3.2mm)

TOPT-LY-731A

Stripping range : 0.13-6mm2

Length : 205mm

TOPT-TP-325

Hydraulic Crimping Tool A hydraulic crimping tool for Copper cable lugs and connectors.

Crimping Type : Indent

Crimping Range : 16mm2 to 400mm2

Output force : 18 Tons Weight / Length : 6.2kg / 650mm (Tool only)

Set includes : Crimping Tool and 4pcs of Male dies (16, 25-35, 50-120, 150-400mm2 )

8pcs Female Dies (16-25, 35-70, 95-120, 150, 185, 240, 300 & 400mm2 ) Carrying case

TOPT-TP-420H

Hydraulic Crimping Head A hydraulic crimping head for Copper cable lugs and connectors.

Crimping Type : Hexagon

Crimping Range : 35mm2 to 400mm2

Jaw Opening : 42mm C-Jaw

Output force : 12 Tons

Weight / Length : 5.3kg / 250mm (Head only)

Set includes : Crimping Tool and 10pcs of dies set

(35, 50, 70, 95, 120, 150, 185, 240, 300 & 400mm2 ) Carrying case

TOPT-HT-85

Hydraulic Cable Cutter Head

Applications : Cutting of Copper & Aluminium PVC Cable

Input Pressure : Max 700bar or 10,000psi

Opening Jaw : 85mm

Cutting Range : Up to 85mm OD (for Telephone Cu/Al Cable) Up to 50mm OD (for Underground Cable)

Length : 456mm

Weight : 6kg

Note : DO NOT use it to cut any rebar, steel wire or armoured cables.

TOPT-S-100H

Hydraulic Cable Cutter Head

Applications : Cutting of Copper & Aluminium Cable including Armoured Cable

Input Pressure : Max 700bar or 10,000psi

Opening Jaw : 100mm

Cutting Range : Up to 100mm OD

Total Length : 570mm

Weight : 14kg

TOPT-CPC-85A

Hydraulic Cable Cutter Head

Applications : Cutting of Copper & Aluminium PVC Cable

Cutting Range: Bare Copper Wire Strand Max. O.D. 28mm, Bare Aluminium Wire Stand Max. O.D. 38mm, CCP Cable Max. O.D. 50mm

Length: 695mm

Weight: 7kg

TOPT-SN-06WF

For wire ferrule and end sleeve.

Ratchet type. Premium handle.

Crimping range: 0.25 – 6mm2

Weight: 0.35kg

TOPT-DL-10A

For wire ferrule and end sleeve.

Ratchet type. Ergonomic double color handle.

Crimping range: 0.08 – 10mm2

Weight: 0.6kg

TOPT-DL-16A

For wire ferrule and end sleeve.

Ratchet type. Ergonomic double color handle.

Crimping range: 0.05 – 16mm2

Weight: 0.6kg

TOPT-SN-01BM3

For ATX, PCI, EPS, Molex Female Connector Pin

Crimping range: 0.05 – 0.8mm2

Weight: 0.35kg

TOPT-FN-13C

For close end terminal

Oval shape crimping

Crimping range: 0.5 – 6mm2

Weight: 0.6kg

TOPT-AC-210

Hand Cutter.

Application: Spring Wire, Cable, Steer Bar and ACSR.

Weight: 2.1kg

TOPT-MK-250

Hand Cutter.

Application: Copper and Aluminium Cable

Cutting Range: 250mm2

Weight: 1.6kg

TOPT-LY-700F

Wire Stripper.

Stripping Range: 0.2 – 6mm2

Length: 170mm

TOPT-PA-6B

A pneumatic type crimping tool for connectors.

Output force: 1.3 tons output at air pressure 5 bars

Weight: 2.7kg

TOPT-AP-901

Air Hydraulic Pump

Max. Pressure: 7-10 bars air pressure /9 CFM air consumption

Weight: 6.7kg

TOPT-FT-L0415

Fish Tape/ Wire Guide

Made of high tensile and durable POM Plastic.

Tape diameter: 4.5mm

Length: 5m

Safety load: 80kg

Breaking strength: 135kg

TOPT-FT-L0450

Fish Tape/ Wire Guide

Made of high tensile and durable POM Plastic.

Tape diameter: 4.5mm

Length: 50m

Safety load: 80kg

Breaking strength: 135kg

TOPT-FT-W0815

Fish Tape/ Wire Guide

Three-ply fish tape (Red+Yellow)

Tape diameter: 7mm

Length: 15m

Safety load: 650kg

Breaking strength: 950kg

TOPT-OP-60D

Double Acting Hydraulic Crimping Head

Crimping type: Hexagon

Crimping range: For connector or lug up to O.D 60mm

Output force: 60 tons output/ 38mm stroke

Oil volume: 308c.c

Weight: 28kg

EPB-4301

12 Tons Cordless Crimping Tool (18V)

43mm C-jaw opening

Insulated fixed knob

Crimping range: 35-400mm2

Weight: 6.8kg excludes battery

EPB-6301

18 Tons Cordless Crimping Tools (18V Li-Ion)

360 degrees swivel head. Pistol type crimper.

Crimping range: 35-630mm2

Weight: 7.4kg excludes battery

MEPB-22

6 Tons Cordless Crimping Tool (18V Li-Ion)

180 degrees swivel head. Inline type crimper/ Flip-open jaw type.

Crimping range: 6-300mm2

Weight: 3.1kg excludes battery

ECB-65Y

12 Tons Cordless Cable Cutter (18V Li-Ion)

For Copper, Aluminium and Lead-sheathed cables.

Armored underground cable cutting 360 degree swivel head.

Weight: 11.3kg excludes battery

ECB-67

Mechanism Cordless Cutters (18V Li-Ion)

Copper and Aluminium cables: DIN cable Max. 1000mm2 (2000MCM)

Max. blade opening : 65mm

Weight: 2.8kg excludes battery

ECB-45

6 Tons Cordless Cable Cutter (18V Li-Ion)

360 degrees swivel head. Pistol type cutters.

Weight: 5.8kg excludes battery
